SCHARNIER 120X60MM INOX 237-NI-120-60-A-GS
02742709
-
GANTER
A055684
120
Stainless steel
60 mm
EA
Currently out of stock
13 day(s) lead time
Product description:
Specification:
- Types
- Type A: 2x2 bores for countersunk screws
- Type C: 2x2 threaded studs
- Version in Zinc die casting ZD
- Zinc die casting ZD
- Plastic coated
- Black, RAL 9005, textured finish SW
- Silver, RAL 9006, textured finish SR
- Pin, Stainless Steel AISI 303 (A2)
- Threaded stud (type C)
- Stainless Steel AISI 316
- Version in Stainless Steel (only type A) NI
- AISI CF-8
- Matt shot-blasted GS
- Pin, Stainless Steel AISI 316Ti (A4)
Information
- Hinges GN 237 with extended hinge wings are made in a compact and sturdy design.
- They are used when larger spacings are required for the attachment bore holes.
