NIVELLEERVOET ZWART LV.A-60-14 ELESA

Product description:

Specification:

• Material:
  • Glass-fibre reinforced polyamide based (PA) technopolymer, black colour, matt finish.
• Bases without no-slip disk:
  • LS.A (D = 25 - 32 - 40 - 50 mm): base without ground mounting.
  • LV.A (D = 60 - 70 - 80 - 100 - 125 mm): base without ground mounting.
  • LV.F ( D = 80 - 100 - 125 mm): base with two holes at 180° for ground mounting, supplied covered by a diaphragm (which can be easily removed by a metal tool) to avoid all unhealthy deposits of dirt and dust when only one hole is used (see Fig.1).
  • LV.FO ( D = 60 - 80 mm): base with with two holes for ground mounting, supplied covered by a diaphragm (which can be easily removed by a metal tool) to avoid all unhealthy deposits of dirt and dust when only one hole is used (see Fig.1).
• Bases with no-slip disk assembled:
  • NBR rubber no-slip disk, hardness 70 Shore A.
  • The particular assembling system of the no-slip disk to the base assures a perfect anchoring, preventing separation even in case of impact during transport or of adhesion (sticking) to the floor (see No-slip discs).
    • LS.A-AS (D = 25 - 32 - 40 - 50 mm): base without ground mounting.
    • LV.A-AS (D = 60 - 70 - 80 - 100 - 125 mm): base without ground mounting.
    • LV.F-AS (D = 80 - 100 - 125 mm): base with two holes at 180° for ground mounting, supplied covered by a diaphragm (which can be easily removed by a metal tool) to avoid all unhealthy deposits of dirt and dust when one only hole is used (see Fig.1).
    • LV.FO-AS ( D = 60 - 80 mm): base with two holes for ground mounting, supplied covered by a diaphragm (which can be easily removed by a metal tool) to avoid all unhealthy deposits of dirt and dust when only one hole is used (see Fig.1).
