MEETBRUG R25-70MM VR MEETKL.21FAJ394 MITUTOYO

Product description:

• This indicator allows you to use a calculation function for the measured value Ax+B+Cx^-1
  • The integrated calculation formula is useful in a variety of applications (e.g. roll diameter measurement)
  • Coefficients A,B and C are freely definable. X = displacement of the plunger
  • Analogue bar graph in the display (14 different scales switchable)
  • GO/±NG tolerance judgement function
  • MAX/MIN/RANGE function to measure peak values
  • A fast measurement frequency mode(detection cycle 20ms or 50times/s) is selectable to measure in the peak detection mode (MAX/MIN/RANGE) more reliably
  • Easy indicator setup via a setup menu
  • A USB interface box can be used to set up the indicator from PC via dedicated software
