51 TONNE CAPACITY, LIGHTWEIGHT ALUMINIUM, DOUBLE ACTING CYLINDER - HRA502 - HI-FORCE

Product description

• Lightweight aluminium cylinder for applications where weight and portability are critical
• Dual-action design increases efficiency through improved performance
• Hard anodised plunger and cylinder for corrosion resistance and increased durability
• Handles fitted as standard on models of 50 tonnes and above
• Bearing surfaces with minimal friction
• Anti-extrusion seals for improved high-pressure performance
• Steel base plate fitted on all models
• External pressure relief valve
• Pushing force capacity: 51 tonnes
• Stroke length: 51 mm
• Oil capacity: 361.5 cm³
• Cylinder lifting surface: 70.9 cm²
• Construction height: 221 mm
• Cylinder diameter: 135 mm
• Piston diameter: 79 mm
• Weight: 10.0 kg
• Max. working pressure: 700 bar
• Complete with quick-release coupling
