50 TONNE CAPACITY, SINGLE ACTING, LOW HEIGHT CYLINDER - HLS502 - HI-FORCE
06002655
5056388007181
HI-FORCE
HLS502
127 mm
126 mm
50 t
60 mm
EA
In Stock: Available
6 day(s) lead time
Product description
- Single-acting, spring return
- Compact design with optimum stroke lengths
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction F
- Anti-extrusion seals for improved performance at high pressure
- Capacity: 50 tonnes
- Stroke length: 60 mm
- Oil capacity: 428 cm³
- Cylinder diameter: 127 mm
- Piston diameter: 70 mm
- Weight: 10.4 kg .
- Construction height: 126 mm
- Max. working pressure: 700 bar
- Complete with quick-release coupling
