4.5 TONNE CAPACITY, SINGLE ACTING MULTI-PURPOSE CYLINDER - HSS53 - HI-FORCE
06002849
5056388008812
HI-FORCE
HSS53
38 mm
157 mm
4,5 t
75 mm
EA
In Stock: Available
6 day(s) lead time
Product description
- Single-acting, spring return
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction
- Anti-extrusion seals for improved high-pressure performance
- Sleeve thread suitable for full load
- Slotted saddles fitted as standard on all models
- Capacity: 4.5 tonnes
- Stroke length: 75 mm
- Oil capacity: 48 cm³
- Construction height: 157 mm
- Cylinder diameter: 38 mm
- Piston diameter: 24 mm
- Weight: 1.4 kg
- Max. working pressure: 700 bar
- Complete with quick-release coupling
