33 TONNE CAPACITY, SINGLE ACTING, HOLLOW PISTON CYLINDER - HHS302 - HI-FORCE
06002625
5056388007013
HI-FORCE
HHS302
115 mm
165 mm
33 t
50 mm
EA
In Stock: Available
6 day(s) lead time
Product description
- Single-acting, spring return
- Hollow plunger design for tool, maintenance and chucking applications
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction
- Anti-extrusion seals for improved high-pressure performance
- Bearing thread suitable for full load
- Capacity: 33 tonnes
- Stroke length: 50 mm
- Oil capacity: 233 cm³
- Construction height: 165 mm
- Cylinder diameter: 115 mm
- Piston diameter: 60 mm
- Weight: 10.6 kg
- Inner diameter plunger: 35 mm
- Connection plunger: 4.1/2"-12
- Max. working pressure: 700 bar
- Complete with plunger saddle and quick-release coupling
