25 TONNE CAPACITY, SINGLE ACTING MULTI-PURPOSE CYLINDER - HSS256 - HI-FORCE
06002832
5056388008713
HI-FORCE
HSS256
86 mm
273 mm
25 t
150
EA
In Stock: Available
6 day(s) lead time
Product description
- Single-acting, spring return
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction
- Anti-extrusion seals for improved high-pressure performance
- Sleeve thread suitable for full load
- Slotted saddles fitted as standard on all models
- Capacity: 25 tonnes
- Stroke length: 150 mm
- Oil capacity: 524 cm³
- Construction height: 273 mm
- Cylinder diameter: 86 mm
- Piston diameter: 54 mm
- Weight: 9.6 kg
- Max. working pressure: 700 bar
- Complete with quick-release coupling
