109 TONNE CAPACITY, SINGLE ACTING, LOW HEIGHT CYLINDER - HLS1002 - HI-FORCE
06002636
5056388007105
HI-FORCE
HLS1002
178 mm
143 mm
109 t
60 mm
EA
In Stock: Available
6 day(s) lead time
Product description
- Single-acting, spring return
- Compact design with optimum stroke lengths
- Nitrocarbonised plunger for corrosion resistance
- Bearing surfaces with minimal friction F
- Anti-extrusion seals for improved high-pressure performance
- Capacity: 109 tonnes
- Stroke length: 60 mm
- Oil capacity: 921 cm³
- Cylinder diameter: 178 mm
- Piston diameter: 114 mm
- Weight: 24 kg
- Construction height: 143 mm
- Max. working pressure: 700 bar
- Complete with quick-release coupling
